本噴砂機適用于10-490mm直徑怎么算的各種各樣類件的外內面手工diy工作噴砂高空作業,除掉外面的灰塵、面除銹防銹、面強化木紋地板、提生低質度、清理面應力比等。(假如:電飯煲、杯具、不粘鍋、電話表殼、網吧電腦表殼、扇葉、切割片性功能下降)可按顧客讓訂做單治具或雙治具。
The sandblasting machines apply to 10-490 mm diameter of of all kinds of the internal and external surfaces of the manual operation sandblast homework, remove the dirt, surface derusting appearance, surface strengthening and improving roughness, removing surface stress, etc. (for example: electric meal bao, cup with, titanium, cell phone casing, computer shell, impeller, saw blades, etc) make single or double position according to customers' special requirements.
◆一般工藝參數表 Main technical parameters
產品應用 Model |
STR-A1500型十三槍圓板轉臂式 |
STR-A1600型八槍園盤轉回式 |
STR-A1600型十四槍圓輪轉回式 |
空機長度 Complete machine size(mm) |
1500×2160×3000 |
1600×1800×2500 |
2200×2400×3000 |
工作中艙尺碼 Working class size(mm) |
Φ1400 |
Φ1500 |
Φ2000 |
排塵箱長寬比 Dedust box sizes(mm) |
1000×1200×2500 |
1000×1200×2500 |
1400×1400×2500 |
小轉盤數 The small turntable for |
16個 |
8個 |
8個 |
噴槍數 Gun number |
12把 |
8把 |
14把 |
電源線 Power |
380V單相電 |
380V三相四線電 |
380V三相電源電 |
照明 Floodlight |
2盞防爆設備燈 |
2盞防爆型燈 |
2盞隔爆燈 |
機權重 Machine weight |
800kg |
750kg |
800kg |
