◆商品優勢特點 Product features
此機型為兩用型模具及滾筒噴砂機,產品類小工件產品可以批量生產用滾筒來生產提高了生產產量,重型工件可以使用轉臺降低工人的勞動強度,大大的滿足了客戶的需求。
The machine is available mould and roller sandblasting machine, Class products can batch production small workpiece with roller to improve manufacturing output, Heavy workpiece can use turntable to reduce the labor intensity, Fully meet the customer's requirements.
◆最主要的技術性叁數 Main technical parameters
刷卡機技術參數 Model |
STR-1010滾筒模具兩用噴砂機 |
事業艙盡寸 Internal size(mm) |
1000×1000×790 |
整個機械長寬高 Complete machine size(mm) |
1000×1540×1830 |
供電 Power |
220V 50Hz |
機器人照指路明燈具燈 Machine floodlight |
220V 13W綠色建筑燈 |
分離法器電動機 Separator motor |
220V 50Hz 550W |
提取器功率 Separator air volume |
8.5m3/min |
壓縮視頻廢氣源 Compressed air source |
2-8bar(kg/cm2) |
轉臺網套直徑 Turntable diameter(mm) |
500 |
轉臺樓板承重 Turntable bearing |
150kg |
滾筒樓板承重 Roller bearing |
10-30Kg |
器機總重量 Machine net weight |
380 kg |
